- Product introduction
- Construction features
- Technical data
-
- 商品名称: FRP series
- 商品编号: FRP
The normal power standard is 220V 50Hz single phase.
Three phase 220/380V/50Hz, 220/440V/60Hz,
Single phase 230V, 240V, 127V, 11OV, 115V/60Hz models are available on request
-
- Pump body: Seal mounting
- Pump foot and diffuser: Glass loaded/polypropilen
- Impeller: Glass loaded noryl
- Motor shaft: Stainless steel AISI420
- Mechanical seal: Graphite and Alumine
- Motor housing: Aluminium L-2521.
- Windings impregnated with epoxy resin
MOTOR:
Asynchronous, two poles.
IP55 protection .
Class Finsulation .
Continuous operation.
Built-in thermal protection .
Quiet running single-stage centrifugal pump,
complete with prefilter.
APPLICATIONS:
Recycling of water from small transportable pools.
-
