- 商品名称: JETP series
- 商品编号: JETP
The JETP series pumps are with pump body and spare parts in plastic, find many uses in domestic applications, gardens and supply water from wells, and so on.
These pumps are suitable for clean water and chemically aggressive liquid. They are very light reliable, safe and simple to use.
-
- Pump body: Plastic(reinforced ABS)
- Impeller: Plastic
- Motor: Closed, externally ventilated
- Insulation class: B(Class F if required)
- Protection class: IP44/IP54
- Duty: Continuously rated
- Mechanical seal: φ 12 ceramic/steatite/graphite
- Shaft: Stainless steelAISI 420
- Thermal Protector
The normal power standard is 220V 50Hz single phase.
Three phase 220/380V/50Hz,220/440V/60Hz,
Single phase 230V, 240V, 127V,110V, 115V/60Hz
models are available on request
-
