- Product introduction
- Construction features
- Technical data
-
- 商品名称: JET-S SERIES
- 商品编号: JET-S SERIES
The JET-S series pumps are with an automatic ejector system, find many uses in domestic applications, gardens and supply water from wells and SO on. These pumps are suitable for clean water and chemically non-aggressive liquid. They are very reliable，safe and simple to use.
-
- Pump body: Cast iron
- Impeller: Brass(noryI if required)
- Motor: Closed, externally ventilated
- Insulation class: B(Class F if required)
- Protection class: IP44/IP54.
- Duty: Continuously rated
- Mechanical seal: φ 12 ceramic/steatite/graphite
- Shaft: Carbon steel AISI 1045(Stainless steel AISI 420 if required)
- Thermal P rotector
The normal power standard is 220V 50Hz single phase.
Three phase 220/380V/50Hz, 220/440V/60Hz,
Single phase 230V, 240V, 127V, 110V, 115V/60Hz
models are available on request
-
DIMENSIONS
TYPE
DIMENSIONS(mm)
a f h H1 H2 W1 W2 n n1 g s JET-40A
94 366 178 90 130 89 60 142 96 7 8 JET-60S
90 380 196 98 152 79 55 182 142 9 11 JET-80S
90 380 196 98 152 79 55 182 142 9 11 JET-100S
90 380 196 98 152 79 55 182 142 9 11 TYPE power Ampere
1~220V
R.P.M Q.Max
(I/min)
H.Max
(m)
S.Head
(m)
Pipe Dia L*W*H
(mm)
N.W
(kg)
HP KW JET-40S
0.45 0.33 2.7 2850 40 35 9 1"*1" 410*210*220 10.2 JET-60S
0.5 0.37 3 45 38 13.0 JET-80S
0.75 0.55 3.6 50 45 13.5 JET-100S
1 0.75 4.8 60 48 14.1 JET-40A
0.45 0.33 2.7 43 40 11.0 JET-40T
0.5 0.37 3 43 43 11.5
