- Product introduction
- Construction features
- Technical data
-
- 商品名称: CM SERIES
- 商品编号: CM SERIES
The pump is suitable for civil and industrial uses to pump clean water and chemically non-aggressive liquid. They have a compact size and are extremely reliable, very simple to use and almost maintenance-free.
-
- Pump body: Cast iron
- Impeller: Brass(Cast iron if required)
- Motor: Closed, externally ventilated
- Insulation class: B(Class F if required)
- Protection class: IP44/IP54
- Duty: Continuously rated
- Mechanical seal: φ 12, φ 16 ceramic steatite/graphite
- Shaft: Carbon steel AISI 1045(Stainless steel AISI 420 if required)
The normal power standard is 220V 50Hz single phase.
Three phase 220/380V/50Hz, 220/440V/60Hz,
Single phase 230V, 240V, 127V, 110V, 115V/60Hz models are available on request
-
DIMENSIONS
TYPE
DIMENSIONS(mm)
a f h H1 H2 n n1 W W1 b g s CM-20/T
45 305 208 82 126 150 99 40 65 40 10 9 CM-70/T
63 370 282 104 178 196 146 63 78 50 13 11 CM-80/T
63 370 282 104 178 196 146 63 78 50 13 11 CM-90/T
63 420 282 104 178 196 146 63 78 50 13 11 TYPE power Ampere
R.P.M Q.Max
(I/min)
H.Max
(m)
S.Head
(m)
Pipe Dia L*W*H
(mm)
N.W
(kg)
HP KW 1~220V 3~380V CM-20/T
1 0.75 5 2.7 2850 200 16.5 9 1½"*1½" 350*180*215 12 CM-70/T
1.5 1.1 7.5 2.7 450 20 2"*2" 395*235*315 22 CM-80/T
2 1.5 9.5 3.5 450 25 23.5 CM-90/T
3 2.2 13.5 5 500 30 410*230*310 28
